Product Description:
The MPO backbone fiber optic cable circular tail sleeve fiber optic
pigtail patch cord created by JFOPT provides an efficient and
stable solution for modern network communications with its
excellent performance and versatility.
JFOPT's MPO backbone optical cable circular tail fiber pigtail
patch cord, with its excellent transmission performance and
stability, can easily cope with various complex network
environments and provide powerful solutions for data centers,
enterprise networks and broadband access. support.
We always adhere to strict quality control standards to ensure that
every jumper reaches carrier-grade quality to protect your network
communications. Choose JFOPT and choose a stable, efficient and
reliable multi-functional network solution.
Features:
1. High Quality Fiber Core
Our fiber cores are of the highest quality, providing excellent
performance for all your transmission needs. With stable
transmission, you can trust that your data will be transmitted
quickly and efficiently, up to 40G.
2. Dust Cap Protection
We understand the importance of keeping your connectors safe and
protected from dust and debris. That's why our fiber cores come
equipped with dust caps and protective ceramic connectors.
3. Durable and Tensile
In addition to being environmentally friendly, our fiber cores are
also durable and tensile. The outer coating is made of
flame-retardant LSZH material, providing excellent wear resistance.
4. Environmentally Friendly LSZH Material
At our company, we care about the environment and strive to make
sustainable choices. That's why our fiber cores are made from new,
environmentally friendly LSZH material.
Technical Parameters:
Product Name: | MPO Trunk Cable |
Cable Sheath Material: | PVC/LSZH/OFN/ONFR/OFNP |
Cable Type: | Single-Tube Mini Cable |
Connector Gender: | Male/Female |
Application: | Optical Module Interconnect |
Jacket Material: | LSZH/PVC/TPU |
Connector Polish: | PC, UPC, APC |
Core Model: | MPO-Multimode OM3 |
Outer Jacket Color: | Aqua |
Cable Length: | 1M |
Cable Color: | Aqua |
| Ferrule type | Insertion loss | Return loss |
| Typical | Maximum |
| SM standard loss | 0.20dB | ≤0.75dB | ≥ 60dB (APC 8°) |
| SM low loss | 0.10dB | ≤0.35dB |
| MM standard loss | 0.20dB | ≤0.6dB | ≥ 20dB |
| MM low loss | 0.10dB | ≤0.35dB |
| MT Ferrule Options |
| Fiber mode | Performance | Fiber count |
| Single mode | Standard loss | 12 (1x12) |
| 24 (2x12) |
| Low loss | 12 (1x12) |
| Multimode | Standard loss | 12 (1x12) |
| 16 (1x16) |
| 24 (2x12) |
| 32 (2x16) |
| Low loss | 12 (1x12) |
| 24 (2x12) |
| Cable Parameter |
| Items | Specifications |
| Fiber Count | 2 | 4 | 6 | 8 | 12 | 24 |
| Fiber | Diameter | 250±15μm |
| Color | Blue/Orange/Green/Brown/Gray/White/Red/Black/Yellow/Purple/Pink/Aqua |
| Strength Member | Aramid Yarn |
| Outer Jacket | Diameter | 3.0±0.2mm |
| Material | PVC /LSZH |
| Color | Blue/Orange/Green/Brown/Gray/White/Red/Black/Yellow/Purple/Pink/Aqua |
| Mechanical performance |
| Items | Specifications |
| Fiber Count | 2 | 4 | 6 | 8 | 12 | 24 |
| Tensile Strength (Long Term) / N | 80 |
| Tensile Strength (Short Term)/ N | 150 |
| Crush Resistance (Long Term) / N/10cm | 150 | 100 |
| Crush Resistance (Long Term) / N/10cm | 500 |
| Min. Bend Radius (Dynamic) / mm | 20D |
| Min. Bend Radius (Static)/ mm | 10D |
| Operating Temperature/℃ | -20～+60 |
| Storage Temperature/℃ | -20～+60 |
| Fiber Parameter |
| SM: |
| Items | Unit | G.652D | G.657A1 | G.657A2 |
| Mode Field Diameter | 1310nm | μm | 9.1±0.4 | 8.8±0.4 | 8.8±0.4 |
| 1550nm | μm | 10.4±0.5 | 9.8±0.5 | 9.8±0.5 |
| Cladding Diameter | μm | 125±1 | 125±0.7 | 125±0.7 |
| Cladding Non-Circularity | % | ≤1 | ≤0.7 | ≤0.7 |
| Core-Cladding Concentricity Error | μm | ≤0.6 | ≤0.5 | ≤0.5 |
| Coating Diameter | μm | 245±7 | 245±5 | 245±5 |
| Coating Non-Circularity | % | ≤6.0 | ≤6.0 | ≤6.0 |
| Cladding-Coating Concentricity Error | μm | ≤12.0 | ≤12.0 | ≤12.0 |
| Cable Cutoff Wavelength | nm | λcc≤1260 | λcc≤1260 | λcc≤1260 |
| Cable Attenuation Coefficient | 1310nm | dB/km | ≤0.4 | ≤0.4 | ≤0.4 |
| 1550nm | dB/km | ≤0.3 | ≤0.3 | ≤0.3 |
| MM: |
| Items | unit | 62.5/125 | 50/125 | OM3-150 | OM3-300 | OM4 |
| Core Diameter | μm | 62.5±2.5 | 50±2.5 | 50±2.5 | 50±2.5 | 50±2.5 |
| Cladding Diameter | μm | 125±1.0 | 125±1.0 | 125±1.0 | 125±1.0 | 125±1.0 |
| Core Non-Circularity | % | ≤5.0 | ≤5.0 | ≤5.0 | ≤5.0 | ≤5.0 |
| Cladding Non-Circularity | % | ≤1.0 | ≤1.0 | ≤1.0 | ≤1.0 | ≤1.0 |
| Core-Cladding Concentricity Error | μm | ≤1.5 | ≤1.5 | ≤1.0 | ≤1.0 | ≤1.0 |
| Coating Diameter | μm | 245±7 | 245±7 | 245±7 | 245±7 | 245±7 |
| Coating Non-Circularity | % | ≤6.0 | ≤6.0 | ≤6.0 | ≤6.0 | ≤6.0 |
| Cladding-Coating Concentricity Error | μm | ≤12.0 | ≤12.0 | ≤12.0 | ≤12.0 | ≤12.0 |
| OFL Bandwidth | 850nm | MHz·km | ≥160 | ≥500 | ≥700 | ≥1500 | ≥3500 |
| 1300nm | MHz·km | ≥500 | ≥500 | ≥500 | ≥500 | ≥500 |
| Cable Attenuation Coefficient | 850nm | dB/km | ≤3.0 | ≤3.0 | ≤3.0 | ≤3.0 | ≤3.0 |
| 1300nm | dB/km | ≤1.0 | ≤1.0 | ≤1.0 | ≤1.0 | ≤1.0 |
Applications:
The MPO Trunk Cable is ideal for various applications, including:
- Data Centers
- Telecommunication Networks
- High-speed Internet Connections
- Network Interconnectivity
- Cloud Computing
- Video Conferencing
- Online Gaming
The MPO Trunk Cable is a high-density interconnect solution that
offers reliable and efficient connectivity for data centers and
telecommunication networks. With its high-speed transmission, low
insertion loss, and high return loss, it is a cost-effective and
versatile option for various applications. Its flexible design and
easy installation make it a popular choice for network connectivity
needs. Choose JFOPT's MPO Trunk Cable for a reliable and
high-performing fiber optic cable solution.
Customization:
We provide customized MPO Trunk Patch Cord solutions for your
specific needs. Our Patch Cords are made with high-quality
materials and are designed to meet international standards. Trust
JFOPT for all your Fiber Optic Cable needs.
Certification: CE, ISO9001
Our MPO Trunk Patch Cords are certified by CE and ISO9001, ensuring
the highest quality and reliability.
Minimum Order Quantity: 1
No matter the size of your project, we can provide you with the
necessary MPO Trunk Patch Cords, starting from a minimum order
quantity of 1.
Price: NA
Our prices are competitive and depend on the customization options
chosen for your MPO Trunk Patch Cord. Contact us for a quote.
Packaging Details: Carton box
Each MPO Trunk Patch Cord is carefully packaged in a sturdy carton
box to ensure safe delivery.
Delivery Time: 5-8 working days
With our efficient production process, we can deliver your
customized MPO Trunk Patch Cord within 5-8 working days.
Payment Terms: T/T, AliPay, PayPal
We offer flexible payment options for your convenience, including
T/T, AliPay, and PayPal.
Supply Ability: 1000 pcs/day
Our state-of-the-art production facility allows us to provide a
large supply of MPO Trunk Patch Cords, with a capacity of 1000 pcs
per day.
Cable Type: Single-Tube Mini Cable
Our MPO Trunk Patch Cords are made with a single-tube mini cable,
providing a compact and lightweight design for easy installation.
Connector: MPO-MPO
The MPO Trunk Patch Cord is equipped with MPO-MPO connectors for
fast and efficient connectivity.
Outer Jacket Color: Aqua
The outer jacket of our MPO Trunk Patch Cord comes in a vibrant
aqua color, making it easily identifiable and adding a touch of
style to your network setup.
Core Model: MPO-Multimode OM3
The MPO Trunk Patch Cord is designed with a MPO-Multimode OM3 core
model, providing high-speed data transmission for your network.
Cable Length: 1M
We offer the MPO Trunk Patch Cord in various cable lengths, with 1M
being the standard length. Custom lengths are also available upon
request.
For all your Patch Cord needs, choose JFOPT for top-quality
products and reliable customization services.
Packing and Shipping:
Our MPO trunk cables are carefully packaged and shipped to ensure
they arrive at your doorstep in perfect condition. Here's what you
can expect when you order our MPO trunk cables:
Packaging:
- All MPO trunk cables are individually packaged in a protective
plastic bag to prevent any damage during transit.
- Multiple MPO trunk cables are then placed in a sturdy cardboard box
with proper cushioning material to avoid any movement or impact
during shipping.
- The box is sealed and labeled with the product name, quantity, and
any other necessary information.
Shipping:
We offer various shipping options to meet your specific needs. Our
standard shipping method is through reputable courier services,
such as UPS or FedEx. We also offer expedited shipping for urgent
orders.
Once your order is shipped, we will provide you with a tracking
number so you can easily track its delivery status.
Please note that shipping costs may vary depending on your location
and the quantity of MPO trunk cables ordered. Any additional
customs or duty fees will be the responsibility of the buyer.
For bulk orders, we can also arrange for special shipping
arrangements, such as using pallets or crates, to ensure safe and
efficient delivery.
FAQ:
- Brand Name: JFOPT
- Model Number: MPO 10G Multi-mode OM3 Fiber Optic Patch Cord
- Place of Origin: CHINA
- Certification: CE, ISO9001
- Minimum Order Quantity: 1
- Price: NA
- Packaging Details: Carton box
- Delivery Time: 5-8 working days
- Payment Terms: T/T, AliPay, PayPal
- Supply Ability: 1000 pcs/day
